TORMACH 1500MX

Epoxy Granite Frame (made in the USA): Epoxy granite frames have 10x the damping of cast iron, resulting in better surface finishes and 30% longer tool life.

4HP, 10K RPM Spindle (Max 6HP): Power at the right RPM range to leverage modern, highly efficient, high speed tool paths.

1200 IPM X/Y & 600 IPM Z: Rapid and cut at up to 1200 IPM keeps up with advanced, constant-engagement tool paths.

Thru-Spindle Coolant Ready: Every 1500MX comes ready for TSC if you choose to add it later. TSC is 7x faster for drilling holes, results in smoother finishes, helps make more consistent parts, and extends tool life.

Servo Motors with Absolute Encoders: 23 bit absolute position encoders with battery backup. The 1500MX’s servos mean you never have to reference the machine, even between power cycles.

TECHNICAL SPECIFICATIONS

TravelsX-Axis19.7 in. (500 mm)
Y-Axis13.8 in. (350 mm)
Z-Axis14 in. (356 mm)
Spindle Nose to Table3.7-17.7 in. (96-450 mm)
SpindleSpindle Power (Continuous)4 hp (3 kW)
Spindle Power (Peak)6 hp (4.5 kW)
Spindle Speed250-10,000 RPM
Spindle TaperBT30
Thread MachiningRigid Tapping
Maximum Feed RatesX- and Y-Axis1,200 IPM (30.5 m/min)
Z-Axis600 IPM (15.2 m/min)
Power and AirPower RequiredSingle-Phase 230 Vac, 50/60 Hz, 30A breaker*
Plug TypeNEMA L6-30P
Air Required90-120 psi
Machine SpecificationsTable Size35 in. × 12.75 in. (0.9 m × 0.3 m)
Typical System Footprint (including coolant tank)86 in. × 104 in. × 94 in. (2.2 m × 2.6 m × 2.4 m)
Typical System Weight2800 lbs. (1270 kg)
Maximum Weight on Table300 lbs. (136 kg)
PerformanceTestingBallbar testing on every machine
Key ComponentsFrameBonded epoxy granite base and column castings
WaysLinear rails
Motion SystemEtherCAT control system
ShippingPallet WeightFactory assembled: 3210 lbs. (1456 kg)
Self assembled: 2650 lbs. (1202 kg)
Crate DimensionsFactory assembled: 68 in. × 74 in. × 89 in. (1.7 m × 1.9 m × 2.3 m)
Self assembled: 54 in. × 58 in. × 8 (1.4 m × 1.5 m × 2.3 m
Optional Accessories16-pocket automatic tool changer (ATC)
microARC 6 – 6 in. (150 mm) 4th axis rotary table
36-gallon flood coolant tank and manual sprayer
Automatic enclosure washdown system
Wireless probe and tool setter
MQL system
Through-spindle coolant (coming fall 2024)
Mist collector (coming fall 2024)
Chip conveyor system (under development)
