High Performance 3D Printing

MARKFORGED ONYX PRO

The workhorse professional 3D printer for Continuous Fiberglass reinforced parts.

Capable of 3D printing Fiberglass-reinforced parts 10x stronger than ABS — the Onyx Pro leverages the power of Continuous Fiber Reinforcement at a competitive price point.

Onyx®

Micro carbon fiber filled nylon offers excellent heat resistance, surface finish, and chemical resistance.

Fibreglass

Inexpensive and 11 times stiffer than ABS, Fiberglass is the perfect entry-level Continous Fiber for 3D printing functional parts.

Smooth TPU 95A

Smooth TPU 95A is a rubber-like material that when used with Markforged composite printers offers product developers and manufacturers the ability to create flexible, impact-absorbent parts on demand.

Precise PLA

Affordable prototyping plastic, available in 8 different colors, engineered to print reliably and accurately.

TECHNICAL SPECIFICATIONS

Printer Properties Process Fused filament fabrication, Continuous Filament Fabrication
Build Volume 320 x 132 x 154 mm (12.6 x 5.2 x 6 in)
Weight 16 kg (35 lbs)
Machine Footprint 584 x 330 x 355 mm (23 x 13 x 14 in)
Print Bed Kinematic coupling — flat to within 160 μm
Extrusion System Second-generation extruder, out-of-plastic detection
Power 100–240 VAC, 150 W (2 A peak)
RF Module Operating Band 2.4 GHz Wi-Fi Standards 802.11 b/g/n
Materials
Plastics Available Onyx, Precise PLA, Smooth TPU
Fibers Available Fiberglass
Tensile Strength 590 MPa (19.0x ABS, 1.9x 6061-T6 Aluminum) *
Tensile Modulus 21 GPa (9.4x ABS, 0.3x 6061-T6 Aluminum) *
Part Properties Layer Height 100 μm default, 200 μm maximum
Infill Closed cell infill: multiple geometries available
Software Supplied Software Eiger Cloud (Other options available at cost)
Security Two-factor authentication, org admin access, single sign-on

The power of continuous carbon fiber at your fingertips
