CALIBRY MINI

Calibry Mini is a hand-held 3D scanner designed to digitize small objects (from 2 cm to 30 cm in length). Blue LED lights ensure high quality of captured data and build-in touchscreen makes scanning easier. The device is lightweight, dependable, and simple to learn.

Accuracy: 0.7mm
Depth of View: 180 – 300 cm
Frame Rate: 25-30 fps
Operating Temp: +5/+40C

TECHNICAL SPECIFICATIONS

Scanner type Handheld
Accuracy Up to 0.7 mm
Accuracy over distance Up to 0.1 mm over 1 m
Point resolution Up to 0.15 mm
Depth of view 180-300 cm
Field of view Min - 86 x 115 mm
Max - 144 x 192 mm
Texture Yes
Light Source Blue LED
Frame Rate 25-30 fps
Data Acquisition speed Up to 3M points/sec
Multi-core Processing Yes
Weight 900 gr (1.9lbs)
Touchscreen Yes, 4 in
Software Yes, included in the price
Operating temperature +5/+40C
